Full Automatic Hydraulic Bucket Handle Making Machine


Full Automatic Hydraulic Bucket Handle Making Machine is used to make bucket handle automatically. This hydraulic bucket handle machine can use steel wire, iron wire, aluminum wire, copper wire, stainless steel wire to manufacturing different shapes and size bucket handle. which just need to change suitable molds .


Advantage Feature of Hydraulic Bucket Handle Making Machine

  1. Hydraulic drive, simple structure
  2. Gears are made by 40Cr, adjusted and quenched, HRC 52-55, shafts are made by 45# steel, adjusted
  3. Feeding & straightening and forming rollers are made by good steel alloy, heat treated HRC 58-62
  4. Automatic feeding plastic tubes for handles by vibrating plate.



Model RMHB-20
Wire Diameter 1.5-5.0mm
Feeding length Can be adjustable
Motor power 5.75kw
Production speed Around 18-22pcs/min
Machine dimension 2100*2150*780mm
Machine weight 1200kg
Power supply Tri-phase


Working Video of Hydraulic Type Bucket Handle Making Machine

Company Profile

We are based in North of China and Have many year expernece for wire processing equipment. Main Product include Nail Making MachineRivet Nail Making MachineRoofing Nail Making Machine, Concrete Nail Making Machine, Wire Drawing MachineNail Polishing MachineNail Galvanizing Machine, Nail Sharpener,  Wire Hanger Making MachineWire Spring Making MachineSteel Chain Making Machine, Bobby Pin Making Machine, Spoke Making Machine, Bucket Handle Making Machine, Wire Mesh Welding Machine, Wire Mesh Weaving Machine, Wire Butt Welding Machine

Now, Our factory has export to Bangladesh, Sudan, Pakistan, Russia, Italy,  Turkey, Egypt , Mexico etc.
